230KW Automatic Diesel Ladle Preheater with Lift & Rotate Function | WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD
Product Introduction:
Optimize your steelmaking process with the high-performance 230KW Diesel Ladle Preheater from WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD.. Designed for heavy-duty industrial applications, this state-of-the-art vertical ladle drying and preheating system ensures efficient, safe, and uniform heating of steel ladles. Whether you are handling online ladles or new offline refractory linings, this equipment delivers rapid heating to prevent thermal shock and extend ladle life.
Engineered for precision, the system features a robust automatic ignition module coupled with a comprehensive safety network. It includes flame failure detection that automatically cuts off the fuel supply, low fuel pressure alarm, and an interlock control system to prevent operational errors. The user-friendly interface, equipped with a digital display, allows operators to monitor real-time temperature and adjust parameters seamlessly, ensuring consistent preheating up to 1100°C.
A standout feature of this industrial ladle heater is its mechanical lift and rotation function. The burner cover can be raised, lowered, and rotated into position with self-locking mechanisms, reducing physical strain on operators and ensuring a tight seal on the ladle for maximum heat efficiency. This design minimizes heat loss and protects the equipment from self-damage during use.
WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. utilizes top-tier global components, including the Riello-style burner and SUNTEC oil pump, ensuring long-term reliability and a combustion efficiency of 98%. This system is ideal for steel plants seeking to enhance productivity, reduce fuel consumption, and maintain strict safety standards.
Key Technical Specifications:
| Parameter | Specification |
|---|---|
| Rated Power | 230 KW |
| Fuel Type | Diesel / Heavy Oil |
| Fuel Consumption | 20 KG/h |
| Max Temperature | 1100°C |
| Heating Rate | Up to 50°C/min (Adjustable) |
| Flame Length | ≥1.2 meters |
| Lifting Range | 1100 - 1500 mm |
| Power Supply | AC 380V / 50Hz |
| Combustion Rate | 98% |
| Burner Type | Long Flame Burner (Riello Technology) |
For more information on ladle preheaters, diesel-fired burners, or steel mill auxiliary equipment, contact WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. today.
